Every now and then you see comments that make you want to laugh, cry or just bang your head against a wall at the stupidity of them. Yesterday there were a couple of such comments from Judith Collins in an opinion piece talking about the Auckland mayoralty. They aren’t really the key part of her opinion but present a good opportunity to bust a few urban myths and concern trolling.
First up one of those old urban legends.
A sprawling city the size of London with a population the size of Perth’s.
There’s couple of interesting aspects to this statement in the comparison of London and Perth.
I’m not quite sure where the comparison with London came about, possibly it was one of those ones from the 50’s and 60’s that was used to justify investing in roads and not in public transport. Regardless of its origin it’s false and presumably only came about by including much of Auckland’s rural hinterland. If we’re talking about cities then we should be comparing the urban area and in that regard London at around 1,738km² is over three times the size of Auckland at 559km². You can clearly see the difference in the image below which shows the two cities at the same scale.
Auckland is a long relatively narrow city due to its geography and would look considerably smaller if it too was on a river plain.
It’s also odd that she chose Perth to compare Auckland too. Perth’s population is now estimated to be over 2 million, a level Auckland is not expected to reach for roughly another 15 years. Of course we’ve already kind of been following Perth for some time when it comes to transport, not least of which included using their old rolling stock until we too electrified our rail network. If we want to continue to follow Perth then more investment in our public transport network and in particular rail will be needed which brings us to the second comment of hers.
Auckland needs roads first and foremost. The Central Rail Link is a good idea and would be a lot better if it included stations at the University of Auckland and AUT. The fact that it won’t include Auckland City Hospital is a lost opportunity. But, then again, Auckland’s hills and gullies make this extremely expensive. Therein lies one of the other issues that London, for example, doesn’t face. Auckland is not flat. It’s built around 60 volcanic cones after all.
The good news for Judith is we have done exactly what she suggests. We’ve spent decades building roads first and foremost and with the exception of a few bits here and there, our road network is largely complete. Once Waterview opens little over a year there will not be any significant gaps in our roading network and all projects after that are tinkering with what we already have. That means for Auckland to move into the future it needs to start focusing on its missing modes, its high quality public transport and active modes networks.
It’s the comment about the CRL not including the Universities and the Hospital that is what really drove me to write this post. It’s classic white anting and the suggestion the CRL route be changed to include these two locations along with Wynyard has been pushed by the NZCID for some time – they are also pushing for a longer and more expensive road tunnel under the harbour. It all reminded me of a document I received from an OIA request over a year ago but never posted. The document is a presentation by the then Minister of Transport to the Cabinet Strategy Committee and is dated 23 August 2013 and I assume Collins was on that committee while she was a minister.
In explaining the CRL it states the CRL is Key infrastructure project for meeting forecast growth in demand for access to Auckland’s city centre It also notes that 14 options for route alignment, number and location of stations were considered in the Options Evaluation Study before determining the preferred route and that the preferred route was endorsed by Auckland Transport, Kiwirail and Auckland Council.
It says the confirmed route is 3.4km long and has the old cost of $2.86 billion.
- Fairly straight alignment, consistent with rail planning principles
- Proven constructability
- Central route covers both sides of CBD
- Significant travel time savings for Western Line passengers.
It then looks at the NZCID route. Notice it is about 800m longer and costs about $800 million more
The stations proposed would obviously have an impact on patronage, the page below doesn’t show the Hospital or Wynyard but as you can see there is little difference in how many people would use alternative route for the Universities.
Modelling of the overall impact of PT patronage out to 2041 shows that in the AM peak there would be a difference of just 150 trips. This is likely because the longer less direct route for some journeys will put a number of people off using PT.
If the small difference in patronage wasn’t bad enough it also turns out the route isn’t feasible as it would require a 9% grade when the maximum for trains is 3.5%. Just eyeballing the graphics also suggests that it would involve some very deep stations.
As for connecting Wynyard, they say AT modelling suggests that on its own it isn’t enough to serve with rail. It doesn’t mention it but to me Wynyard seems much more suited to being a station on a route that connects to the North Shore.
The presentation notes the following conclusions
And the last part of her comment
And we Aucklanders love our cars. Many Aucklanders work in south Auckland and live in west Auckland. That’s the nature of Auckland. Buses travel on roads. Rail is useful and needed but it’s not the only solution.
As I’ve said in the past Auckland’s love affair with cars is more of an arranged marriage due to a lack of quality options.
Yes many people do live in West Auckland and travel to South Auckland for work. However have a play with Statistics NZ interactive commuter map and you’ll see it’s not super significant numbers. Once the new network is in place it will be easier than ever to commute between the two areas. For those that want to drive – which is likely to remain the fastest option – if only there was a road that would let them bypass having to travel through the city to get to the south. Perhaps we could call the road the Western Ring Road. The example below is of commute patterns to the area unit that includes the Airport. Around 1,200 of the nearly 16,000 people who commuted there came from West Auckland
Lastly of course buses travel on roads but they generally do so on local roads, not state highways like the government is prioritising. I look forward to seeing Collins tell us all what roads for buses she is proposing be built.
